HC22 Precision Ground Hollow Cylinder

The precision grinding on both OD and ID ensures concentricity, roundness, and a bore surface finish that prevents turbulence-driven local corrosion and residue trapping — problems you cannot fix in the field after the part is installed. JILAIDA measures bore finish, concentricity, and wall thickness uniformity on every HC22 precision ground hollow cylinder we ship, not as an option but as standard practice. Standard bore finish is Ra 0.8 µm (0.4 or 0.2 µm on request), OD–ID concentricity TIR ≤ 0.5 mm (≤ 0.1 mm on request), and wall uniformity ± 0.5 mm over length (± 0.25 mm UT-mapped on request). We start from solid billet — forging, deep-hole drilling, and OD/ID grinding all in-house — so the geometry is controlled from raw material to finished part under one roof. As a factory-direct China manufacturer, Ji lai da delivers mill-run pricing with no trading markups. The price is the same whether you order one piece or fifty, and the EN 10204 3.1 MTC covering full heat analysis ships with the part, not after it. FOB, CIF, or DDP delivery worldwide. Send your OD, ID, length, and tolerance band to Jiangsu Ji Lai Da Nickel-Based Alloy Co., Ltd. — a written quotation, lead time, and MTC plan returned the same working day.

Three Geometries You Can't Fix Later

A precision ground hollow cylinder is judged on three things you can't fix in the field: bore surface finish, concentricity, and wall thickness uniformity. Bore finish controls the flow boundary layer — a rough bore in a chlorine scrubber distributor creates turbulence that accelerates local corrosion; in a pharmaceutical reactor it traps residue that fails CIP validation. Concentricity decides whether the part installs without shimming and whether the wall carries pressure evenly. Wall uniformity is the one buyers most often miss — a cylinder that measures on nominal wall at the ends can drop 2 mm at midspan, and that thin band is where pressure-cycle fatigue starts. We measure all three on every cylinder we ship, not as an option.

Scrubbers, Reactors, Clean Rooms

Scrubber nozzle bodies, chlorination reactor liners, acid injection mandrels, semiconductor process chambers — the HC22 precision ground hollow cylinder goes into these because 316L pits, C-276 covers most conditions but C-22 adds margin, and the ground bore guarantees a smooth flow path with even wall around the full 360°. Shipped from our mill as a China manufacturer with MTC per EN 10204 3.1. RFQ with your OD, ID, and length.

Four Fields, One RFQ

The four fields we ask for first are OD, ID, length, and the tolerance band you can accept on the OD. Everything else — bore finish in Ra µm, concentricity in TIR, PMI requirement, MTC type, delivery term (FOB Shanghai, CIF Mumbai, DDP Jubail, or your port) — is a line in the same RFQ template. Send a drawing or sketch and we return a quote the same working day. As a factory-direct China supplier the price is the same whether the order is one piece or fifty, and the MTC ships with the part.

Send OD, ID, length, and the tolerance band to start a quote. Drawings welcome — we return a written offer, lead time, and MTC plan the same day.
